DN Solutions BM 1530M, 2035M, 2740M, 2740U

Large-sized High-rigidity High-accuracy Double Column Machining Center– Symmetrical double column structure

– High-speed built-in spindle

– High-rigidity roller guide for all axes

– Diverse options for target industries

Specifications
Classification	Unit	BM 1530M	BM 2035M	BM 2740M	BM 2740U
Effective Width between Columns	mm	1700	2200	2700	2740
X-axis Travel (Table Longitudinal)	mm	3000	3500	4000	4000
Table Size	mm	3000 X 1350	3500 X 1850	4000 x 2500	4000 X 2500
Max. Spindle Speed	r/min	12000	12000	12000	18000
Max. Spindle Motor Power	kW	30	30	30	40
Tooling Taper	taper	50	50	50	HSK-A63
NC System	–	FANUC	FANUC	FANUC	HEIDENHAIN

* Product specifications are subject to change depending on additional functions and options.
