DN Solutions DNM 200/5AX
Product Overview
Compact Process-intensive 5-axis Machining Center – High-rigidity C-type structure
– Machine for beginners in 5-axis machining
– Existing DNM 3-axis equipment-based 5-axis machine
– High-speed and direct-coupled spindle
– High-rigidity roller guides for all axes
Specifications
| Classification | Unit | DNM 200/5AX |
|---|---|---|
| Table Size | mm | ⌀200 |
| Tooling Taper | taper | 40 |
| Travel (X / Y / Z) |
mm | 400 / 435 / 500 |
| Max. Spindle Speed | r/min | 12000 |
| Max. Spindle Motor Power | kW | 18.5 |
| Tool Storage Capacity | ea | 30 |
| NC System | – | FANUC |
| Table Tilting / Rotating Angle (A / C) |
deg | 150 / 360 |
* Product specifications are subject to change depending on additional functions and options.
