DN Solutions HP 4000 II, 5100 II

High-speed High-performance Horizontal Machining Center– High-speed and high-rigidity enabled via the roller guide system for all axes

– Stable precision via the spindle structure enabling speedy acceleration and deceleration (standard: 14000 r/min; option: 20000 r/min)

– High-precision direct-coupled spindle travel and minimization of thermal displacement of ball screws and nuts

– Rotary-type auto pallet changer featuring high reliability and convenient setting

Specifications
Classification	Unit	HP 4000 II	HP 5100 II
Pallet Size	mm	400 x 400	500 x 500
Tooling Taper	taper	40	40
Max. Spindle Speed	r/min	14000	14000
Max. Spindle Motor Power	kW	22	22
Travel (X / Y / Z)	mm	600 / 560 / 600	850 / 700 / 750
Tool Storage Capacity	ea	40	40
NC System	–	FANUC	FANUC

* Product specifications are subject to change depending on additional functions and options.
