DN Solutions PUMA MX1600, MX1600/735

Process-intensive Combined Turning Center – Armed with the functions of turning and machining centers

– Unmanned operation (option) via the bar feeder and gantry loader

– Max. turning length : 900mm

– Up to 9-axis structure

– High-power milling (Y axis) (Y-axis high-speed travel:26m/min)

Specifications
Classification	Unit	PUMA MX1600	PUMA MX1600/735
Max. Turning Diameter	mm	330	330
Max. Turning Length	mm	900 Class	900 Class
Standard Chuck Size (Left / Right Spindle)	inch	6 / 6	6 / 6
Bar Working Diameter	mm	51	51
Max. Spindle Speed	r/min	6000	6000
Max. Spindle Motor Power	kW	15	15
Milling Spindle Speed	r/min	12000	12000
Y-axis Travel	mm	170 (±85)	170 (±85)
NC System	–	FANUC	FANUC
Machining Capability	–	Standards, S, T, ST	Standards, S, T, ST
Capability Description	–	S : Sub-spindle T : Lower turret	S : Sub-spindle T : Lower turret

* Product specifications are subject to change depending on additional functions and options.
